Cosmic® Lift UPS
Cosmic® Lift UPS
Lift UPS Power Generating System with MPPT is Double Conversion with Load Sharing Technology. This is one of the advanced technology in the market to utilize 100% of Solar PV Generated power by enhancing Solar Power through MPPT Load Sharing and current control technology which can be used for sensitive, sophisticated and industrial loads.
Features
- User-friendly installation
- High efficiency and extended backup time
- Noiseless operation
- Uninterrupted power supply
- Pure sine wave output
- Compact and lightweight
Description
Cosmic® Lift UPS is the perfect solution for businesses and homeowners who are looking for a reliable and efficient UPS system. It is suitable for a variety of applications, including elevators and lifts, motors, lighting, and any kind of three-phase load. Cosmic® Lift UPS uses double conversion technology to provide complete isolation of the output load from the input, and its pure sine wave output is ideal for sensitive and sophisticated equipment. It also features a built-in MPPT solar charger, which allows you to maximize your solar power generation and reduce your reliance on grid power.
Specification
| DESCRIPTION | SOLAR SINEWAVE UPS TECHNICAL SPECIFICATION |
|---|---|
| TECHNOLOGY | 3 Phase Line Interactive, IGBT, DSP and PWM based |
| MODEL | CLU 06 to CLU 250 |
| CAPACITY | 6 KVA to 150 KVA |
| AC INPUT Voltage |
415V AC +15% or -20%, 50Hz +/-6Hz 100V – 300V AC for lighting |
| AC OUTPUT Voltage | < 400/415V AC +/- 1%, 3Phase 4 Wire(on Battery Mode) |
| Wave Form | Pure Sinewave |
| Output Power factor and THD |
0.8 to 1Lagging, <3% with Linear load |
| Cooling | > Forced Air |
| Protection |
Input Under and Over Voltage, Single Phase, Reverse Phase, Output Under and Over Voltage, Overload Short Circuit, |
| Communication | RS 232 and SMS Alerts(Optional) |
| Application | Elevators, Lifts, Motors, Lightings or any kond of three phase load |
Frequently Ask Question Now.
What is the capacity of Cosmic® Lift UPS?
Cosmic® Lift UPS is available in capacities ranging from 6 KVA to 150 KVA.
What is the backup time of Cosmic® Lift UPS?
The backup time of Cosmic® Lift UPS depends on the capacity of the battery bank. A 6 KVA Cosmic® Lift UPS with a 120 Ah battery bank can provide a backup time of up to 2 hours.
What are the benefits of Cosmic® Lift UPS?
- Uninterrupted power supply
- Pure sine wave output
- Compact and lightweight
- User-friendly installation
- High efficiency and extended
- backup time
- Noiseless operation
What are the applications of Cosmic® Lift UPS?
Cosmic® Lift UPSs are ideal for use in a variety of applications, including:
- Elevators and lifts
- Motors
- Lighting
- Any kind of three-phase load
What protection features does Cosmic® Lift UPS have?
Cosmic® Lift UPS has the following protection features:
- Input under and over voltage
- Single phase
- Reverse phase
- Output under and over voltage
- Overload short circuit
- Battery low and overcharge with alarm
What protection features does Cosmic® Lift UPS have?
Cosmic® Lift UPS has the following communication features:
- RS 232
- SMS alert (optional)
